Test Patterns from SE

	Comments/Recommendations	Aechelon Path Relative to COMMON\RELEASE\V1\DB\DB_MOVING_MODELS	Aechelon Image
Black Level
Smear	Using AeDisplay the user can pitch, roll, oscillate and turn the pattern on it's side.	RESOLUTION\SMEAR\SMEAR.hie
Continuous FOV	Only have a 10 degree pattern. Need to make a 5 degree checkerboard sphere.	CONTRAST\CONTRAST_SPHERE\CONTRAST_SPHERE_5DEG.hie (still needs to be in RELEASE\V1)
Continuous Geometry		GEOMETRY\5DEG_WHITE_LINE_GRID_BLACK_SPHERE\5DEG_WHITE_LINE_GRID_BLACK_SPHERE.hie
Surface Contrast Ratio	Need white square in the middle of each channel. Can quickly provide single white square pattern, but would need several weeks to provide a process for a full field pattern with multiple white squares		Add the white bright box to a black background pattern - manually for now, then figure out an automated way to do it
Light Point Size	NOTE: May need to add goal posts to our current pattern.	MISC\LIGHT_POINT_SIZE_48X4DEG\LIGHT_POINT_SIZE_48X4DEG.hie
Light Point Contrast Ratio	Need to add process for putting it in the middle of each channel if desired.	MISC\LIGHT_POINT_CONTRAST_40X40X4DEG\LIGHT_POINT_CONTRAST_40X40X4DEG.hie
Surface Resolution/Vernier Resolution?	Piano Keys. We have a lot of resolution patterns with alternating black and white bars. The guides seem to indicate a "runway" setup is desired with a certain width, length and piano key spacing on a 3 degree glideslope.
Surface Highlight Brightness	Can quickly put together a pattern with a single black box of a specified size, but will need time to develop a process for getting one in the center of each channel.
